do88 BigPack Intercooler and Pipe Kit Toyota GR Yaris
Just changing to this powerful intercooler is a big improvement, along with a pressure line kit the improvement is huge! The pressure pipes have significantly better air flow than the stock pipes, verified by several tests both in the car and on the SuperFlow SF-1020 custom flow stool.
Product detailed description
Advantages of do88 BigPack:
- Larger core volume: 13,971cc vs. 7,320cc, 91% bigger!
- Larger active cooling area, 2451 cm2 vs. 913 cm2, 168% larger!
- Larger input/output connection: 63mm (2 1/2”) versus 45mm (1 3/4”), 95% more area!
- Air flow at 0.175 bar/2.54 psi pressure drop: 284 CFM vs. 203 CFM, 40% higher!
- Peak power of 26 Whp along with the input of the do88 turbo! Measured on a car with a TTE400 turbo, Syvecs ECU, etc.
- Lower air temperature behind the intercooler under the same conditions: 25°C (50°C), 25°C lower!
Suitable for Toyota GR Yaris cars manufactured from 2020.
The BigPack includes an all-aluminum performance intercooler and a complete set of 2 and 2 1/8” pipes and silicone hoses. This BigPack replaces everything between the turbo outlet and the throttle body, drastically improving airflow and cooling performance. The powerful do88 intercooler is an all-aluminum construction. With CAD designed flow optimized cast end tanks along with an optimized core design it achieves the best possible cooling efficiency combined with the lowest possible pressure drop! Pressure pipes are manufactured from 2 and 2 1/8” mandrel-bent seamless aluminum tubing. Custom made high quality silicone hoses with 4 layers of polyester/aramid reinforcement. These hoses can handle very high temperature and pressure!
